  • 140 Amp Multi MIG/TIG/MMA Inverter Welder
Picture of 140 Amp Multi MIG/TIG/MMA Inverter Welder
Picture of 140 Amp Multi MIG/TIG/MMA Inverter Welder
140 Amp Multi MIG/TIG/MMA Inverter Welder
High quality, multi-functional welder that combines MIG, TIG and MMA processes into a single welder. The welder is ideal for garage, bodyshop and general workshop welding. Weighing just over 14kg and with a convenient carry handle for manoeuvrability, the welder provides great versatility, being able to weld 0.6mm, 0.8mm, 0.9mm and 1.0mm welding wire. This welder can output between 30 - 140A, dependent on type of welding, with an input of 230V/50Hz - 1 Phase, welding steel with a material thickness range of 1 - 6mm. It is also supplied with a 2.3m torch cable, offering greater operating range. The welder is fitted with a 32A industrial plug.

Features efficient inverter technology that has a high switching frequency, making the unit more efficient than traditional non-inverter transformer-type welders. It also benefits from turbo fan cooling for prolonged welding and greater efficiency.

Supplied with;
1x Inverter Welder
1x Gas Hose
1x MIG Torch

  • 1x Electrode Holder

  • 1x Gas Bottle Holder assembly

  • 1x Chipping Hammer and Wire Brush

  • 1x Welding Mask Assembly

  • 1x Tip Changing Spanner

  • 1x 0.8mm Welding Wire MSW

  • 1x 0.9mm Welding Wire Fluxed Cord

  • 1x 0.6mm Roller

  • 1x 0.8mm Tip

  • 1x 0.9mm Tip

Products in this range
Download data sheets
Prod. code Cat. code Description Price QTY.
764-0151 MIG150 140 Amp Multi MIG/TIG/MMA Inverter Welder
Price Exc VAT (Inc VAT)
  • Suitable for MIG, TIG & MMA Welding
  • Min/Max Output Current: 30A - 140A
  • Electrode Diameter: 1.6 - 3.2mm (MMA) / 1.6 - 2.4mm (TIG)
  • Input voltage: 230V/50Hz
  • Maximum Input Current (Max/Eff): 24A / 13.1A
  • Welding thickness: 1.0 - 6.0mm (Mig) 1.0 - 4.0mm (Tig) 1.0 - 6.0mm (MMA)
  • Welding wire diameter: 0.6mm, 0.8mm, 09mm, 1.0mm
  • Supplied with welding mask
  • Peak Input Power: 5500W

Technical Specifications;

Min/Max Amps: 30-140
Power Supply: 32A Plug
Input Voltage: 230V
Welding Wire Size: 0.6-1.0mm
Mild Steel Capacity: 6mm
No Gas/Gas: Gas
Packaged Weight: 15.13Kg
